Ray Allen T2-7A Trim Servo

Ray Allen T2-7A Trim Servo

Prix habituel $416.00 CAD
Prix habituel Prix promotionnel $416.00 CAD
Frais d'expédition calculés à l'étape de paiement.

Part Number: 11-02048

Overview

This servo is built to actuate trim surfaces on homebuilt aircraft, and can also drive other onboard mechanisms in place of cables and pulleys. It runs on 12-14 volts DC and produces high force output through a jackshaft mechanism, which holds the output shaft locked in place whenever power is off. Travel stops automatically at the end of its range, and movement only occurs when the pilot supplies power; the direction of travel depends on voltage polarity. No onboard electronics are used to manage its operation.

Specifications

  • Part Number : 11-02048
  • Series : T2
  • Model : T2-7A
  • Travel : .7" (17mm)
  • Voltage : 12-14 volts DC
  • Drive Mechanism : Jackshaft

Please Note

  • Catalog description specifies 'Servo Only' – other components may not be included
