• Lamar Solenoid 12V 100A Continuous X61-0028
1 1

Lamar Solenoid 12V 100A Continuous (X61-0028)

Lamar Solenoid 12V 100A Continuous (X61-0028)
$167.75 CAD
$167.75 CAD
Shipping calculated at checkout.

6 in stock

Condition: New

Lamar Solenoid — 12 Volt, 100 Amp continuous duty. MFR X61-0028.

Part Number : 07-01875. MFR model # : X61-0028.

Overview

Aviation grade solenoid for continuous-duty 12 volt applications (non FAA-PMA approved). Fits current GA production aircraft as well as legacy aircraft. Replaces both single-terminal switched units and the current double-terminal switched units in production today. All units undergo multiple quality and functional tests prior to certification and delivery.

Features

  • Replaces most contactors in general aviation.
  • 12 Volt unit.
  • Continuous duty — suitable as a Master / battery solenoid (not for use as a starter relay).
  • Externally grounded; can be mounted in any position, including on a metal battery box.
  • All units inspected and tested to performance standards.

Specifications

  • Rating: 12 V, 100 A continuous duty.
  • Large studs interchangeable (100 A each); small posts — one switched positive, one ground — interchangeable.
  • Terminal posts: front two 10-32 UNF-2A; larger side posts 5/16-24 UNF-2A.
  • Weight: approx. 0.95 lb.
  • Not FAA-PMA approved; may be installed in a certified aircraft only via a 337 field approval.

Documents

Tech Data Sheet & Drawing · Standard Installation Diagram
